The knowledge of steel angle

The following paper will take you to know about the knowledge of steel angle and the steel angle manufacturer. The steel angle is a long piece of steel with two sides perpendicular to each other. Its specifications are expressed in millimeters of side width × side width × side thickness. For example, "∠25×25×3" means an equilateral steel angle with a side width of 25 mm and a side thickness of 3 mm. It can also be expressed by the model, the model is the number of centimeters of the side width, such as ∠3#. The model does not indicate the size of different side thicknesses in the same model, so the side width and side thickness of the steel angle should be filled in on the contract and other documents to avoid using the model separately. The specification of hot rolled equilateral steel angle is 2#-20#.

The steel angle can be composed of various stress-bearing components according to the different needs of the structure, and can also be used as a connecting piece between components. It is widely used in various building structures and engineering structures, such as beams, bridges, transmission towers, lifting and transporting machinery, ships, industrial furnaces, reaction towers, container racks and warehouse racks. Steel angle is a carbon structural steel for construction, which is a simple section steel, mainly used for metal components and the frame of the workshop. In use, it is required to have good weldability, plastic deformation performance and certain mechanical strength.

The types and specification of steel angle

It is mainly divided into two types: equilateral steel angle and unequal steel angle. Among them, unequal steel angle can be divided into unequal and unequal thickness and unequal and unequal thickness. The specification of the steel angle is expressed by the dimensions of side length and side thickness. Since 2010, the domestic steel angle specifications are 2-20, and the number of centimeters on the side is the number. The same steel angle often has 2-7 different side thicknesses. The imported steel angle indicates the actual size and edge thickness of both sides and the relevant standards. Generally, those with a side length of more than 12.5cm are large steel angles, those between 12.5cm and 5cm are medium-sized steel angles, and those with a side length of less than 5cm are small steel angles.

The recommendation of steel angle manufacturer

There exists an excellent and reliable steel angle manufacturer-TJYCT Steel Co., Ltd. which can take you to know about the knowledge of steel angle and other steel products. Welcome you to know more knowledge about steel angle and other steel products.
