What is the carbon steel pipe

The carbon steel pipe is made of steel ingots or solid round steel through perforation to make capillary tubes, and then made by hot rolling, cold rolling or cold drawing. Carbon steel pipe plays an important role in my country's steel pipe industry. The following paper will take you to know about the carbon steel pipe and the specification of carbon steel pipe as well as the carbon steel pipe manufacturer.

The specification of carbon steel pipe

The carbon steel pipe is divided into two categories: hot-rolled and cold-rolled (drawn) steel pipes. Hot-rolled carbon steel pipe is divided into general steel pipe, low and medium pressure boiler steel pipe, high pressure boiler steel pipe, alloy steel pipe, stainless steel pipe, petroleum cracking pipe, geological steel pipe and other steel pipes. In addition to general steel pipes, low and medium pressure boiler steel pipes, high pressure boiler steel pipes, alloy steel pipes, stainless steel pipes, petroleum cracking pipes, and other steel pipes, cold-rolled (dial) carbon steel pipes also include carbon thin-walled steel pipes, alloy thin-walled steel pipes, Stainless thin-walled steel pipe, special-shaped steel pipe. The outer diameter of hot-rolled seamless pipes is generally greater than 32mm, and the wall thickness is 2.5-75mm. The outer diameter of cold-rolled seamless pipes can reach 6mm and the wall thickness can reach 0.25mm. The outer diameter of thin-walled pipes can reach 5mm and the wall thickness is less than 0.25mm. Cold rolling has higher dimensional accuracy than hot rolling.

General carbon steel pipe: It is made of 10, 20, 30, 35, 45 and other high-quality carbon steel 16Mn, 5MnV and other low-alloy structural steel or 40Cr, 30CrMnSi, 45Mn2, 40MnB and other alloy steel hot-rolled or cold-rolled. Seamless pipes made of low carbon steel such as 10 and 20 are mainly used for fluid transportation pipelines. 45, 40Cr and other medium carbon steel seamless pipes are used to manufacture mechanical parts, such as the stressed parts of automobiles and tractors. Generally, carbon steel pipe is used to ensure the strength and flattening test. Hot-rolled steel pipes are delivered in hot-rolled or heat-treated state; cold-rolled steel pipes are delivered in heat-treated state. I believe you have known about the specification of the carbon steel pipe.

How to produce the carbon steel pipe

The raw material of The carbon steel pipe is a round tube blank, which is cut by a cutting machine into a billet with a length of about 1 meter, and sent to a furnace for heating through a conveyor belt. The billets are fed into the furnace and heated at about 1200 degrees Celsius. The fuel is hydrogen or acetylene. The temperature control in the furnace is a key issue. After the round tube blank is released from the furnace, it must be pierced by a pressure piercer. Generally, the more common punching machine is the conical roller punching machine. This kind of punching machine has high production efficiency, good product quality, large amount of perforation and expansion, and can wear a variety of steel grades. After perforation, the carbon steel pipe is successively cross-rolled, continuously rolled or extruded by three rolls. After extrusion, the tube should be removed and sizing. The sizing machine rotates into the steel billet at high speed through the conical drill bit to punch holes to form steel pipes. The inner diameter of the carbon steel pipe is determined by the outer diameter of the drill bit of the sizing machine. After sizing, the steel pipe enters the cooling tower and is cooled by water spray. After the carbon steel pipe is cooled, it will be straightened. The carbon steel pipe is straightened and sent to the metal flaw detector (or hydraulic test) by the conveyor belt for internal flaw detection. If there are cracks, bubbles and other problems inside the steel pipe, it will be detected. After the steel pipe quality inspection, it must pass strict manual selection. After the quality inspection of the steel pipe, the serial number, specification, production batch number, etc. are sprayed with paint. And lifted into the warehouse by crane.

The excellent and reliable carbon steel pipe manufacturer

The excellent and reliable carbon steel pipe manufacturer-TJYCT Steel Co., Ltd. will take you to know about knowledge of carbon steel pipe. If you want to buy high-quality carbon steel pipe, you can visit the website of TJYCT Steel Co. , Ltd. Welcome you to visit the website of TJYCT Steel Co., Ltd.
