Large diameter SS304 SS316 Stainless Steel Welded Round Pipe
    Time：2023/02/13

    The Specification and Size Of Stainless Steel Welded Pipe

    Available Specification

    Product NameExecutive StandardDimensionSteel Code / Steel Grade
    Industrial Pipes

    ASTM A312, A358, A778
    JIS G3459

    		OD: 1/4"~40"
    WT: SCH5S~SCH80S    		TP304, TP304L, TP316L, SUS304TP
    Tubes for Boiler and Heat-Exchanger, General Service TubingASTM A249, A269, JIS G3463OD: 15.9~139.8mm
    WT: 1.6~5.0mm    		TP304, TP304L, TP316L, SUS304TB
    Mechanical and Structural TubesASTM A554, JIS G3446OD: 7.9~152.4mm
    WT: 0.5~6.5mm    		MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD SUS304
    Square TubesASTM A554OD: 12.7x12.7~150x150mm
    WT: 0.7~6.5mm    		MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD
    Rectangular TubesASTM A554OD: 10x20~100x200mm
    WT: 0.7~6.5mm    		MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD
    Sanitary TubingASTM A270
    JIS G3447    		OD: 25.4~165.2mm
    WT: 0.8~3.05mm    		TP304, TP304L, TP316L, SUS304TBS
    Large Gauge Pipes for Ordinary PipingJIS G3448OD: 15.88~318.5mm
    WT: 0.8~3.0mm    		SUS304TPD
    Large Diameter PipesJIS G3468OD: 14"~40"
    WT: SCH5S~SCH40S    		SUS304TPY


    We also accept customized sizes. If the size you need is not in the table above, please consult us. We provide all sizes of products! If you need Chemical Composition and Mechanical Property, Pls contact us to get them!


    Contact Us Now To Get Preferential Price!(About 10% to 20% Discount)


    Contact Our Sales Manager By Email - yctsteel9@gmail.com Quote


    Contact Our Sales Manager By Message - Contact Us Quote



    The Application Of Stainless Steel Welded Pipe

    Stainless steel welded pipe, referred to as welded pipe for short, is a steel pipe welded by common steel or steel strip after being crimped and formed by machine set and mold. Stainless steel pipe (pipe) has excellent corrosion resistance and finish Usually used in automobile industry, food processing industry, water treatment industry, oil industry, natural gas industry, oil refining industry, petrochemical industry, brewery and energy industry.


    - Automotive industries


    - Food processing


    - Water treatment facilities


    - Breweries and energy industries


    The Images Of Stainless Steel Welded Pipe






    welded pipe

    welded pipe
